고온용 Dry Block

고온용 Dry Block

CALsys 1500L / Autocal (500 ~ 1500°C)
  • 고온용 Dry Block
  • CALsys 1500L or CALsys 1500L/Autocal 선택 가능
  • Temp range : 500 ~ 1500°C
  • Controlling sensors: R type duplex
  • Method of Control: Self tunned PID controller
  • Calibration: Accredited calibration certificate provided
견적문의 Data sheet

제품 사양

Model CALsys 1500L / Autocal
Temp range 500 ~ 1500°C
Stability ±0.4°C at 500°C
±0.6°C at 1000°C
±1.0°C at 1500°C
Uniformity ±0.6°C at 500°C
±0.8°C at 1000°C
±1.2°C at 1500°C
Controlling Sensor R type duplex
Stabilization time 15 to 20 mins
Immersion depth 140 mm
Insert dimensions 37 mm
Method of Control Self Tuned PID controller
Heating time 2 Hrs
Resolution 1 °C
Computer Interface Ethernet port (CALsys 1500L Autocal), RS - 232(CALsys 1500L)
Input (CALsys 1500L Autocal) Four channels (one master and three test sensors).
high-quality universal LEMO connector suitable both for T/C (J, K, N, T, R, S, B type) and Rtd
Software (CALsys 1500L Autocal) The calibrator will be provided with software for data recording (Manual Mode ) and Test Certificate in Auto Mode
Data logging (CALsys 1500L Autocal) Data logging facility with logged data export to the computer through LAN port ( optional USB)


제품 상세 설명

  • Wide Operating Range (500 to 1500°C)
  • excellent calibration accuracy with stability ±1.0°C
  • PC interfacing
  • Accredited calibration
